首頁 > 產品中心 > PJRCL熱處理真空爐系列 > PJY2系列油淬真空爐

立式多功能淬火真空爐

主要用于合金鋼、合金結構鋼、工模具鋼、彈簧鋼、軸承鋼、不銹鋼、精密合金鋼等材料的光亮淬火、調質及磁性材料的燒結，光亮退火及真空釬焊，該設備適用于細長軸，薄壁長件，大型超重件

分享商品：

銷售電話：15318905266

立式多功能淬火真空爐

產品名稱：立式多功能淬火真空爐

Name: Vertical Multifunctional Quenching Vacuum Furnace

規格：見技術參數 /Specification: Refer to technical parameters

用途：主要用于合金鋼、合金結構鋼、工模具鋼、彈簧鋼、軸承鋼、不銹鋼、精密合金鋼等材料的光亮淬火、調質及磁性材料的燒結，光亮退火及真空釬焊，該設備適用于細長軸，薄壁長件，大型超重件

Application: It is mainly used for bright quenching, quenching and tempering of alloy steel, alloy structural steel, work die steel, spring steel, bearing steel, stainless steel, precision alloy steel and other materials. It is suitable for slender shaft, thin-wall long piece and large-scale overweight part.。　

特點/Characteristics:

1.加熱元件沿加熱室圓周360度均勻布置，溫度均勻性達±5℃

The heating element is evenly arranged along the circle of the heating chamber at 360 degrees, and the temperature uniformity is up to ±5 ℃.

2. 加熱室與淬火室分開，可選擇性淬火（油淬/氣淬/水淬）

The heating chamber is separated from the quenching chamber and can be selectively quenched (oil quenching,/gas quenching/water quenching).。

3.淬火攪拌機構變頻調速且?guī)в袑?dǎo)流裝置，冷卻均勻性好、工件變形小

The quenching mixing mechanism has variable frequency speed regulation and flow diversion device, good cooling uniformity and small deformation of the workpiece.

4.具有恒溫油淬火/等溫淬火/對流加熱/真空分壓

With constant temperature oil quenching / Isothermal quenching / convective heating / vacuum partial pressure

5.氣淬采用高效外循環風機，冷卻速度提高80%

The high efficiency external circulation fan is used for gas quenching, and the cooling rate can be increased by 80%.。

6.全智能化工業計算機控制系統并有一套手動操作系統

Fully intelligent chemical industry computer control system and a manual operating system。

7.操作簡潔編程工藝靈活輸入機械動作穩定可靠

The operation is simple and the programming process is flexible, and the mechanical action is stable and reliable.

8.手動/半自動/自動 故障自動報警/顯示

Manual / semi-automatic / automatic fault automatic alarm / display

配置選擇/Configure select:

雙室垂直結構形式： Double chamber vertical structure form：

整體式

Unitary

加熱室移動式

Heating chamber mobile

淬火槽移動式

Quenching tank mobile

中間隔熱門：Middle septum hot：

機械傳動 Mechanical drive

氣動 /Pneumatic

淬火槽攪拌方式： Quenching tank stirring mode：

漿葉攪拌

Pulp blade stirring

噴嘴噴射

Nozzle injection

二者疊加

Superposition of the two

爐膽/flue：

石墨加熱元件與石墨氈復合屏合成結構；

Synthesis structure of Graphite heating element and Graphite felt Composite screen

鉬加熱元件與金屬隔熱屏合成結構；

The composite structure of Mo heating element and metal thermal insulation screen;

鎳鉻合金帶加熱元件與不銹鋼屏合成結構；

Synthesis structure of Ni-Cr Alloy Strip heating element and stainless Steel screen

真空泵組和真空計；

Vacuum pump set and vacuum gauge：

進口

Imported

高品質國產

High quality domestic

真空度：

Vacuum degree：

高真空

High vacuum

中真空

Medium vacuum

PLC:

西門子

Siemens

歐姆龍

OMRON

三菱

Mitsubishi

溫控儀表

Thermostat meter：

歐陸

EUROTHERM

導電

Electric conduction

熱電偶 :

Thermocouple：

S型分度號

S-type dividing number

記錄儀 :

Grapher :

有紙記錄儀

Paper recorder

無紙記錄儀

Paperless recorder

人機界面:

Human-computer interface

模擬屏

Analog screen

計算機觸摸屏

Computer touch screen

電器元件

Electrical component：

高品質國產

High quality

Made in China

施耐德

Schneider

西門子

Siemens

產品 規格/ Specifications：

注：特殊規格要求可根據客戶要求定制

Note: Special specification requirements can be customized according to customer requirements

以下參數可根據工藝要求調整，不作為驗收依據，具體以技術方案和協議為準

The following parameters may be adjusted according to the process requirements and shall not be used as the basis for acceptance, depending on the technical scheme and agreement.

參數/型號 Parameter/ Model	PJ-LY68	PJ-LY810	PJ-LY1012	PJ-LY1215	PJ-LY1518
有效熱區D×H(mm） Effective hot zone	600×800	800×1000	1000×1200	1200×1500	1500×1800
裝載重量（KG） Load weight	500	800	1000	1200	2000
最高溫度（℃） Max.temprature	1150/1350	1150/1350	1150/1350	1150/1350	1150/1350
爐溫均勻性（℃） Furnace temperature uniformity	±5	±5	±5	±5	±5
真空度（Pa） Vacuum degree	4.0 E -1/ 6.7 E -3	4.0 E -1/ 6.7 E -3	4.0 E -1/ 6.7 E -3	4.0 E -1/ 6.7 E -3	4.0 E -1/ 6.7 E -3
壓升率（Pa） Pressure rise rate	≤0.5	≤0.5	≤0.5	≤0.5	≤0.5
移送時間 Transfer time（S）	≤37	≤45	≤55	≤70	≤83
